Our BMW Wheel Spacers Adapters are engineered specifically for the full range of BMW internal combustion and new energy vehicles, fitting mainstream models such as the 1, 3, 5, and 7 Series, as well as the X-series SUVs. We maintain in-house production, plating, and quality control lines, selling spacers bundled with matching high-strength wheel nuts produced in the same facility. Unlike traders who source components piecemeal, we control the entire process from raw material intake to finished product output. We cater to the bulk procurement and custom development needs of modification shops, overseas wholesalers, and auto parts chains, with products exported to markets across North America and Western Europe.
1. Comprehensive coverage of the entire BMW passenger vehicle lineup: Sedans (1–8 Series), SUVs (X1–X8), i-Series new energy vehicles, and MINI models.
2. Standard in-stock thicknesses include 5mm, 8mm, 10mm, 12mm, 15mm, 20mm, 25mm, 30mm, and 35mm; non-standard thicknesses (40–80mm) are available via custom order based on technical drawings.
3. Center bore and PCD specifications precisely match OEM BMW wheel data, preventing common modification issues such as vibration, tire rubbing against fenders, and premature bearing wear.
4. We offer complete, bundled kits that include matching extended wheel bolts, anti-theft nuts, and hub-centric rings, providing a one-stop solution for modification needs.
|
Product Name |
Universal Wheel Spacer |
|
Brand Name |
J&W Auto Parts |
|
PCD |
5x120 |
|
Thickness |
20mm, 25mm,30mm, 40mm |
|
Country of Origin |
ZheJiang, China |
|
MOQ |
4 PCS |
|
Material |
Aluminium 6061-T6 |
|
PCD(mm/inch) |
CB(mm/inch) |
THICKNESS(mm/inch) |
THREAD |
|
5x114.3/4.5 |
74/2.91 |
31.75/1.25 |
M12x1.5 |
|
5x120.65/4.75 |
87/3.43 |
31.75/1.25 |
M12x1.5 |
|
5x127/5 |
87.18/3.43 |
38.1/1.5 |
1/2-20 |
|
6x139.7/5.5 |
108/4.25 |
50.8/2 |
M12x1.5 |
|
5x150/5.91 |
110/4.33 |
30/1.18 |
M14x1.5 |
|
4x108/4.25 |
71/2.8 |
25.4/1 |
M12x1.5 |
|
5x100/3.94 |
57.1/2.25 |
31.75/1.25 |
M12x1.5 |
|
5x100/3.94 |
57.1/2.25 |
25.4/1 |
M12x1.5 |
|
5x150/5.91 |
110/4.33 |
38.1/1.5 |
M14x1.5 |
|
5x114.3/4.5 |
74/2.91 |
25.4/1 |
1/2-20 |
|
5x112/4.41 |
74/2.91 |
31.75/1.25 |
M14x1.5 |
|
5x114.3/4.5 |
73/2.87 |
31.75/1.25 |
1/2-20 |
|
5x127/5 |
78.1/3.07 |
50.8/2 |
1/2-20 |
|
8x7.09/180 |
126.15/4.97 |
38.1/1.5 |
M14x1.5 |
1. In-house Production: We operate a 10-mu (approx. 6,600 m²) manufacturing facility equipped with over 20 CNC machining centers and 12 large-scale cold-heading machines. Gasket bases are formed via integrated CNC milling—eliminating the need for splicing or secondary welding.
2. Premium Materials: BMW Wheel Spacers Adapters are available in two primary base materials: forged aluminum alloy or high-strength carbon steel. Mill Test Certificates are provided upon material intake, ensuring no recycled scrap or impure materials are used.
3. Advanced Surface Treatment: Equipped with a fully automated electroplating line, the spacers undergo anti-corrosion treatment. Finished products pass 72-hour neutral salt spray tests, ensuring resistance to rust and peeling during long-term outdoor use.
4. Precision Manufacturing: The workshop adheres to standardized 5S management. Individual part tolerances are controlled within 0.02mm, ensuring superior flatness and eliminating vibration during high-speed driving.
1. Raw Material Inspection: Hardness and tensile strength are spot-checked for every batch of aluminum and steel upon arrival; physical and chemical material reports are issued.
2. Corrosion & Durability Testing: All finished products undergo a 72-hour salt spray corrosion test, meeting industry standards for overseas aftermarket automotive parts.
3. Mechanical Load Testing: Third-party testing for load-bearing, compression, and impact resistance ensures suitability for long-term use in high-speed driving and rough road conditions.
4. Comprehensive Final Inspection: Every BMW Wheel Spacers Adapter undergoes manual verification of bolt patterns, thickness, and center bore precision. Defective units are discarded, and qualified products are individually packaged.
5. Certified Quality: Products come with CE compliance certification, ISO quality management system certification, and material test certificates; full documentation is provided for customs clearance and export.
1. Dimensional Customization: We offer custom spacers with non-standard thicknesses, special center bore sizes, and PCD specifications to accommodate niche/vintage BMW models and wide-body modification requirements.
2. Material Customization: Choose between lightweight forged aluminum spacers and high-load carbon steel spacers based on specific needs, suitable for various scenarios ranging from street driving to track racing.
3. Surface Finish Customization: Options include matte, glossy, black oxide, and natural plating finishes.
4. Packaging Customization: Supports private-label neutral packaging, color box printing, and outer carton logo printing to meet the sales needs of private-label wholesalers.
1. Production Capacity: Mature in-house production lines handle large-volume export orders reliably; standard stock spacers ship within 7 days, while custom non-standard models have a 30–40 day production cycle.
2. Established Global Distribution: 60% of products are sold to North America, 12% to Western Europe, and 10% to Oceania; we are well-versed in import customs clearance requirements for automotive parts across these regions.
3. Multi-Channel Logistics: Options include sea freight (FCL/LCL), air freight, and international express delivery; we can deliver to designated domestic freight forwarder warehouses and provide packing lists and customs clearance certificates.
4. Stable Supply Chain: In addition to spacers, we manufacture matching wheel nuts, hub-centric rings, and nut covers in-house, eliminating the need for external sourcing and ensuring reliable, on-time delivery.
1. Sample Service: Free samples are available for verification of dimensions, workmanship, and corrosion resistance before placing bulk orders.
2. Order Progress Updates: We provide real-time updates on production, plating, and packaging stages; customers are notified immediately upon completion to arrange final payment and shipment.
3. After-Sales Support: Should quality issues arise—such as dimensional deviations or plating defects—customers can immediately contact their sales representative to negotiate reasonable solutions, such as replacements, reshipments, or price adjustments.
4. Flexible Procurement: Small-batch trial orders are accepted for standard stock spacers; custom non-standard products have set minimum order quantities (MOQs) that can be discussed individually.
1. Extended wheel bolts and anti-theft wheel nuts (BMW-specific specifications) for a perfect match when purchased with spacers.
2. Hub-centric rings to eliminate the gap between the wheel hub and spacer, preventing high-speed vibration.
3. Plastic decorative nut covers that enhance the wheel's appearance; suitable for overseas retail markets.
4. Heat-insulating exhaust wrap is available through partner suppliers; these can be consolidated into the same shipment for one-stop sourcing of automotive modification parts.
|
Consideration |
Forged Aluminum Alloy (6061-T6) |
High-Strength Carbon Steel |
|
Recommended Use |
Street driving, daily commuting, lightweight wheel setups, NEVs (to minimize unsprung weight and preserve range) |
Track racing, heavy-duty SUVs, off-road, or extreme load conditions where maximum impact resistance is prioritized |
|
Weight |
Lighter – reduces rotational mass |
Heavier – adds durability |
|
Corrosion Resistance |
Naturally corrosion-resistant + electroplated |
Requires electroplating; our 72h salt spray test applies to both |
|
Price Point |
Standard pricing |
Comparable; slight variation based on thickness |
Location: Zhejiang, China – one of the world's largest automotive parts manufacturing clusters, with integrated supply chains for raw materials, plating, and logistics.
Facility Area: 10 mu self-owned production premises.
Key Equipment: 20+ CNC machining centers + 12 large-scale cold-heading machines + fully automated electroplating line.
Quality Systems: ISO 9001-certified quality management system in operation; CE certification available for all exported products.
Testing Capability: In-house 72-hour neutral salt spray tester, hardness tester, and tensile strength testing equipment for incoming material verification.
We welcome third-party factory audits or video inspections upon request.
Should any quality issue arise (dimensional deviation, plating defects, or machining flaws):
Report: Contact your sales representative with photos and batch/lot numbers (if applicable).
Assessment: Our QC team reviews the case against our retained samples and production records.
Resolution: Based on findings, we offer one of the following –
Replacement production (with expedited lead time)
Reshipment at our cost (if the error is on our side)
Price adjustment/compensation for the affected quantity
We maintain traceability records for each batch, enabling rapid root-cause analysis.
Spacers in standard thicknesses for popular BMW models are in stock and ready to ship within 7 days of payment. Niche/older models and custom non-standard thicknesses are not stocked and require a production lead time of approximately 30–40 days.
Custom non-standard spacers have a fixed MOQ; please contact a sales representative for specific quantity requirements. Standard items are kept in stock and are available for small-batch trial orders.
Finished products undergo an automated electroplating process and pass a 72-hour neutral salt spray test, ensuring resistance to corrosion and rust during daily street and rainy-weather driving. For track use or highly corrosive environments (such as saline coastal areas), we offer custom options with thicker plating for enhanced durability.
If you discover quality issues—such as dimensional deviations, plating flaws, or machining defects—upon receipt, please contact your sales representative immediately and provide photographic evidence. We will provide solutions based on the specific situation, such as replacements, reshipment, or price adjustments/compensation.
BMW dealers generally do not void a vehicle's warranty solely for using wheel spacers, provided the parts are properly installed and do not directly cause a failure. However, if a suspension or wheel bearing issue arises and the spacer is identified as the root cause, the dealer may deny that specific claim. Our spacers are designed to OEM specifications (hub-centric, correct center bore, precision-machined) to minimize any risk of interference. We recommend keeping your original wheels and bolts for inspection purposes if you are concerned about warranty coverage.
It depends on the spacer thickness:
For spacers under 15mm: The original wheel bolts may protrude beyond the spacer surface. In this case, we supply matching extended bolts with every kit – no cutting or modification is required.
For spacers 15mm and above: The spacer design includes recessed bolt holes that accommodate the original bolts, and our extended bolts are used to secure the wheel.
We do not recommend cutting original bolts – it weakens the thread integrity and compromises safety. Our kits eliminate this need entirely.
Our in-house engineers can assist with:
Fitment verification for your specific BMW model
Custom thickness and PCD recommendations
Material selection advice based on your driving conditions
OEM comparison and dimensional drawing requests
